YT 34 Multi Box corner
Colour: aluminum
Material: aluminum 6082
Number of points: 4-point
Edge dimension: 29cm
System: YT34
Type: corner
Main Pipe Diameter:50mm
Wall thickness main pipe:3mm
Brace diameter:20mm
Wall thickness Brace:2mm
YT34PL truss system
| Standard available lengths and codes | |||
|---|---|---|---|
| Metres | Feet | Weight(kg) | Code |
| 0.50 | 1.64 | 5.00 | YT34050PL |
| 1.00 | 3.28 | 7.30 | YT34100PL |
| 1.50 | 4.92 | 9.60 | YT34150PL |
| 2.00 | 6.56 | 12.00 | YT34200PL |
| 2.50 | 8.20 | 14.00 | YT34250PL |
| 3.00 | 9.84 | 16.40 | YT34300PL |
| 3.50 | 11.48 | 18.70 | YT34350PL |
| 4.00 | 13.12 | 21.00 | YT34400PL |
| 4.50 | 14.76 | 23.30 | YT34450PL |
| 5.00 | 16.40 | 25.50 | YT34500PL |
| other lengths available on request | |||
parameter
- Colour: Black / Aluminum (Other colours available on request)
- Material: aluminum 6082
- Number of points: 4-point
- Edge dimension: 29cm
- System: YT34PL
- Type: straight
- Truss length: 0.5-5m
- Main Pipe Diameter: 48mm
- Wall thickness main pipe: 3mm
- Brace diameter: 16mm
- Wall thickness Brace: 2mm
DOWNLOAD
Accessories
-
YT 34 Multi Box corner -
YT 34 PL 2-way corner -
YT 34 PL 2-way corner -
YT 34 PL 2-way corner -
YT 34 PL 2-way corner -
YT 34 PL 2-way corner -
YT 34 PL 3-way corner -
YT 34 PL 3-way corner -
YT 34 PL 4-way corner -
YT 34 PL 4-way corner -
YT 34 PL 5-way corner -
YT 34 PL base plate
-
CONTACT US -
YT 34 PL 2-way corner
CONTACT USColour: aluminum
Material: aluminum 6082
Number of points: 4-point
Edge dimension: 29cm
System: YT34PL
Type: corner
Main Pipe Diameter:48mm
Wall thickness main pipe:3mm
Brace diameter:16mm
Wall thickness Brace:2mm
-
YT 34 PL 2-way corner
CONTACT USColour: aluminum
Material: aluminum 6082
Number of points: 4-point
Edge dimension: 29cm
System: YT34PL
Type: corner
Main Pipe Diameter:48mm
Wall thickness main pipe:3mm
Brace diameter:16mm
Wall thickness Brace:2mm
-
YT 34 PL 2-way corner
CONTACT USColour: aluminum
Material: aluminum 6082
Number of points: 4-point
Edge dimension: 29cm
System: YT34PL
Type: corner
Main Pipe Diameter:48mm
Wall thickness main pipe:3mm
Brace diameter:16mm
Wall thickness Brace:2mm
-
YT 34 PL 2-way corner
CONTACT USColour: aluminum
Material: aluminum 6082
Number of points: 4-point
Edge dimension: 29cm
System: YT34PL
Type: corner
Main Pipe Diameter:48mm
Wall thickness main pipe:3mm
Brace diameter:16mm
Wall thickness Brace:2mm
-
YT 34 PL 2-way corner
CONTACT USColour: aluminum
Material: aluminum 6082
Number of points: 4-point
Edge dimension: 29cm
System: YT34PL
Type: corner
Main Pipe Diameter:48mm
Wall thickness main pipe:3mm
Brace diameter:16mm
Wall thickness Brace:2mm
-
YT 34 PL 3-way corner
CONTACT USColour: aluminum
Material: aluminum 6082
Number of points: 4-point
Edge dimension: 29cm
System: YT34PL
Type: corner
Main Pipe Diameter:48mm
Wall thickness main pipe:3mm
Brace diameter:16mm
Wall thickness Brace:2mm
-
YT 34 PL 3-way corner
CONTACT USColour: aluminum
Material: aluminum 6082
Number of points: 4-point
Edge dimension: 29cm
System: YT34PL
Type: corner
Main Pipe Diameter:48mm
Wall thickness main pipe:3mm
Brace diameter:16mm
Wall thickness Brace:2mm
-
YT 34 PL 4-way corner
CONTACT USColour: aluminum
Material: aluminum 6082
Number of points: 4-point
Edge dimension: 29cm
System: YT34PL
Type: corner
Main Pipe Diameter:48mm
Wall thickness main pipe:3mm
Brace diameter:16mm
Wall thickness Brace:2mm
-
YT 34 PL 4-way corner
CONTACT USColour: aluminum
Material: aluminum 6082
Number of points: 4-point
Edge dimension: 29cm
System: YT34PL
Type: corner
Main Pipe Diameter:48mm
Wall thickness main pipe:3mm
Brace diameter:16mm
Wall thickness Brace:2mm
-
YT 34 PL 5-way corner
CONTACT USColour: aluminum
Material: aluminum 6082
Number of points: 4-point
Edge dimension: 29cm
System: YT34PL
Type: corner
Main Pipe Diameter:48mm
Wall thickness main pipe:3mm
Brace diameter:16mm
Wall thickness Brace:2mm
-
YT 34 PL base plate
CONTACT USColour: aluminum
Material: aluminum 6082
Number of points: 4-point
Edge dimension: 29cm
System: YT34PL
Type: Sonderteil
